Arthermo Dial Thermometer

F84-100-FP

Product Description



Telethermometer F84 FP surface mounted type, grey moplen body, capillary mm.1500 3,5 mm PVC coated, temperature range -40+40°C white dial with black numbers and Arthermo logo, free bulb 7,5 mm.


Optional:

  • Different length capillary
  • Compensation of environmental temperature to the reading casing
  • Different size of bulb
  • Different colour of displays and/or number
  • Nipple
  • Different temperature scale
  • Max temperature tolerance casing 40°C
  • Case dimension 60, 80, 100 mm
  • Brass or copper bulb 7.5 mm
  • Copper capillary coated in PVC
  • Casing in material loaded grey resin
  • Frame stainless steel
  • Fastener with screws
  • Temperature range -40·40°C
  • Dial white with black numbers





Resources

Arthermo F84FP Technical Data

Arthermo F84FP Technical Data

21.05 KBPDF
