Optimized for HFC refrigerants and polyolester (POE) or polyalkyl glycol (PAG) oils. 100% 3… Molecular Sieve. Temperature range: -40°C - +70°C.

• Type  DML 304S
• Weight  1.24 Kg
• Acid capacity [g]  6,40 g
• Acid capacity [oz]  0,226 oz
• Approval  UL
• Connection material  COPPER
• Core size  30 cu.in.
• EAN number  5702428159647
• Inlet connection size [in]  1/2 IN
• Inlet connection type  SOLDER, ODF
• Max. Working Pressure [bar]  46,0 bar
• Max. Working Pressure [psig]  667 psig
• Outlet connection size [in]  1/2 IN
• Outlet connection type  SOLDER, ODF
• Temperature range [°C]  -40 - 70 °C
• Temperature range [°F]  -40 - 160 °F
• Type designation  DML 304S
